Unity Elite 10 Pro FB4 (IP65)
Item Code: ELITE10PROFB4IP65
Price: $7,791.00 incl. GST
Minimum : 1
Maximum : 0
If an item is not in stock at our Australian warehouse, it will be shipped directly from our supplier. This may require a lead time of 3–4 weeks.
Please contact us to confirm current stock availability.
UNITY ELITE PRO FB4 SERIES
The ELITE PRO FB4 series lasers are professional systems suitable for hire and touring.
 | Unity ELITE 10 PRO FB4 (IP65) The Elite 10 PRO FB4 (IP65) laser is ideal for venues, lighting designers, SFX and rental companies who prefer direct control of their lasers over DMX and Artnet.
Unity ELITE uses semiconductor laser diodes. It is a full-colour RGB laser with analogue modulation integrated into robust, rain-proof housing.
It is suitable for permanent installations in clubs, touring, and rental situations.
The Elite 10 PRO FB4 (IP65) is suitable for medium-to-large venues and events. |
What is in the Package
| Heavy-duty flight case |
Laser control software |
Laser projector |
Mains cable |
Ethernet cable |
|
E-STOP Remote |
E-STOP XLR cable |
Set of 4 Safety keys | Quality certificate | |
Specifications
| Product Name: | Unity ELITE PRO 10 FB4 (IP65) |
| Type Of Laser: | Full-colour, Semiconductor diode laser system |
| Guaranteed Optical Output: | >10W |
| Suitable For: | Lighting professionals: large indoor venues (up to 10,000 people), medium outdoor shows. Beam show, text, graphic, and mapping capable |
| Control Signal: | Pangolin FB4 DMX [Ethernet, ArtNet, DMX, sACN | PC, Lighting Console, Auto Mode, Mobile App: Apple, Android] |
| Scanning System: | 35,000 points per second @ 8° |
| Scan Angle: | 45° |
| Safety: | Fully complies with the latest EN 60825-1 and FDA regulations |
| Weight: | 12.7kg |
| Package Includes: | Laser projector w/ FB4 DMX, protective case, Estop box, Estop cable (10M/30ft), ethernet cable (10M/30ft), power cable (1.5M/4.5ft), interlock (* service dongle if outside US), keys, outdoor RJ45 connectors, manual, quickstart guide, variance card |
| R | G | B [mW]: | 3,200 | 3,200 | 4,000 |
| Beam Size [mm]: | 6 x 6 |
| Beam Divergence: | <1.2mrad [Full Angle] |
| Modulation: | Analog 100kHz |
| Power Requirements: | 100-240V/50Hz |
| Consumption: | Max. 300W |
| Operation Temperature: | (-10°C) - 45°C |
| Ingress Rating: | IP65 |
| System Features: | All the adjustments, such as power output of each color, X & Y axes invert, X & Y size and position, safety, etc., are managed digitally by the FB4 control system. Ethernet in/out, power in/out, DMX in/out, Estop in/out |
| Laser Safety Features: | Keyed interlock, Emission delay, Magnetic interlock, Scan-fail safety, Mechanical shutter, Adjustable aperture masking plate |
| Notice: | *Due to Advanced Optical Correction technology used in our laser systems, each laser colour's optical power output may slightly differ from the specification of the respective laser module(s) installed. This does not affect the total guaranteed power output |
| Dimensions [mm]: | Depth: 328 | Width: 338 | Height: 191 |
